Product Details:
Payment & Shipping Terms:
|
Capacity:: | 15kg-150kg | Loading Type: | Front Loading |
---|---|---|---|
Raw Material: | Stainless Steel 304 | Heating:: | Electric, Steam, Electric&Steam,Hot & Cold Water |
Voltage: | 110v,220v,380v,400v,440v | Packing: | Pallet Or Wooden Case |
HS Code: | 84502000 | Suspension: | Full Suspension Shock Structure |
Door: | Front And Single | ||
Highlight: | large capacity washing machine,heavy duty washing machine |
Our XGQ line of Softmount Industrial Freestanding washer extractors provides industrial strength washer-extractors with unbeatable pricing. Optional one way tilting make loading and unloading simple and efficient. With capacities from 22 to 200 pounds (15 to 130kg), we have the right sizing for you application. High extraction speeds mean less time in the dryer, yielding tremendous energy and time savings.
· Standard 1 year warranty
· 350G extract force which reduces energy consumption and increases savings
· Advanced Microcomputer, PC programmable, programs transferred via USB
· 5 Compartment supply dispenser for dry and liquid chemicals
· 5 connections for automatic chemical injection
· All parts in contact with the wash solution made of stainless steel.
· Inverter drive - programmable variable speed
· Single motor drive
· Robust spring or Airbag suspension
· Programmable water levels
· Programmable water temperature
· Rear drain connection
High Quality Commercial Laundry Equipment
· For many companies, laundry is a necessary but often overlooked requirement. After all, staff uniforms and all other garments need to be washed to be at their very best. This means many businesses and organisations, from hotels to education centres, need the right commercial laundry equipment to meet their needs.
· We understand the power of laundry equipment, which is why we offer a vast range of machines and appliances to suit all manner of companies. Gamesail has been providing companies with bespoke, quality laundry equipment since 2002 and we’ve been expanding ever since.
·
The Right Product For You
· Different companies have different needs, so the right appliance is essential. For example, traditional washing machines are great for handling large loads, while the likes of barrier washers can provide safe infection control services. If you’re not sure what you need, we can help you find the right tools for the job, choosing from our range of:
· Washing machines,
· Tumble dryers
· Barrier washers
· Ironers
· Folders
· Hydro extractors
· Cloth finishers
· Similarly, you also need to consider the size and dimensions of your work space. We have plenty of experience helping companies large and small. If you have space limitations, we can advise you right options, for instance, to help maximise the productivity and efficiency from every possible area.
·
The Power Of On-site Commercial Laundry Equipment
· If you haven’t invested in commercial laundry equipment yet, you may be wondering why it’s so beneficial. The fact is, if you’re cleaning a large amount of laundry, or even just small loads on a frequent basis, commercial grade appliances are cheaper in the long run.
· Our commercial laundry equipment represents a one-time investment, rather than relying on third party services to clean your fabrics and clothing articles. In time, this laundry equipment will essentially pay for itself through savings. Of course, it’s also much more practical to have this machinery on-site, as it allows you to better integrated it into your work processes.
·
The Right Quality
· We offer best cost performance commercial laundry equipment, helping you to meet all of your needs regardless of your budget. In everything we offer, we can provide after sales agreements as well. This is something many companies are unsure of, yet we have the ideal solution.
· Not only do we provide high quality products every time, we can also agree on maintenance costs upfront, so you always know how much something might cost. If this is something you are concerned about, please get in touch.
· Whether you’re a small firm or a large chain, the right laundry is vital. It keeps your supplies clean and your staff uniforms looking at their best. Investing in commercial grade laundry equipment is an effective way to maintain quality across your entire business. Furthermore, it will save costs from relying on other companies and old equipment. If you’re looking to improve your laundry and washing operations, Gamesail has the appliances for you.
PERSONAL CARD
Parameter
TYPE | XGQ-15FII | XGQ-20FII | XGQ-25FII | XGQ-30FII | XGQ-50FII | XGQ-70FII | XGQ-100FII | XGQ-130FII | |
CAPACITY | |||||||||
Drum capacity | kg | 15 | 20 | 25 | 30 | 50 | 70 | 100 | 130 |
Drum volume | L | 160 | 195 | 250 | 315 | 540 | 708 | 1010 | 1300 |
Number of drums | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
Number ofloading doors | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
Number of unloading doors | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
DRUM SPEED | |||||||||
Washing speed | rpm | 50 | 48 | 45 | 37 | 36 | 35 | 34 | 32 |
Highest spin speed | rpm | 800 | 780 | 750 | 750 | 720 | 700 | 680 | 635 |
G-force | rpm | 230 | 240 | 250 | 285 | 300 | 300 | 300 | 300 |
HEATING | |||||||||
Electric | kw | 14 | 18 | 21 | 21 | 42 | 46 | / | / |
Steam ratio | kg/kg | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 |
CONNECTIONS | |||||||||
Water inlet | ZG1.0" | ZG1.0" | ZG1.2" | ZG1.5" | ZG1.5" | ZG1.5" | ZG1.5" | ZG2.0" | |
Steam inlet | ZG3/4" | ZG3/4" | ZG3/4" | ZG1.0" | ZG1.0" | ZG1.0" | ZG1.0" | ZG1.5" | |
DIMENTIONS | |||||||||
Width | mm | 930 | 1000 | 1150 | 1460 | 1610 | 1650 | 1760 | 1950 |
Depth | mm | 1100 | 1170 | 1220 | 1440 | 1680 | 1960 | 2090 | 2220 |
Height | mm | 1530 | 1560 | 1600 | 1840 | 2040 | 2160 | 1970 | 2175 |
